    GVS/RPB Z4 Welding ADF Lens PAPR Kit

    SKU: 15-018-11-EUUK

    Dual Air Distribution: dual air distribution system delivers 75% to your breathe zone via a multi-directional outlet and 25% is directed over the grinding visor to prevent fogging.

    Easy of use: flip up welding visor for optimum vision during grinding.

    Comfort: comfortable multi-adjustment head suspension system for secure and customized fit.

    Eye protection: clear replaceable grinding lens approved.

    Back

    £1640.45 Ex. VAT Inc. VAT

    In stock
    Picture of GVS/RPB Z4 Welding ADF Lens PAPR Kit GVS/RPB Z4 Welding ADF Lens PAPR Kit £1640.45 Ex. VAT

    Detailed Description

    Z4 Welding Respirator with PX5 PAPR

    With comfort and durability the top priority, we have created the most ergonomically balanced welding respirator available. Its lightweight (805g headpiece) design and multi-adjustment head suspension system ensures a stable fit that moves with you, reducing aches and strains on your neck, allowing you to enjoy life’s best moments.

    The Z4 boasts an optically clear grinding visor and a flip-up welding visor for optimum vision during grinding.
    Visibility is further enhanced by clip-in shade 5 side windows offering maximum peripheral vision. These can also be switched out for window blockers which are included in the standard package.

    The Z4 includes the large ADF lens with 1.1.1 optical quality rating guaranteeing uniform shading and distortion free vision, allowing you to work safely and more comfortably for longer across different angles.

    To further increase your comfort and stability, the Z4 can also be fitted with the Comfort-LinK padding system for an individualized fit.

    40% MORE VIEWING WITH THE OCV ULTRA ADF (110X110)

    Viewing Area: 66.77 square cm
    Light state: Shade 3. Dark state: Selectable shades 9-13
    Fast, reliable switching speed: 0.1ms at 23ºC / 73ºF
    Optional auto delay function from dark to light (0.15 to 1 seconds)
    Weight (ADF only): 130 g
    Temperature range: -20ºC to +50ºC / -4ºF to 122ºF

    3 year warranty
    2 Sensors, plus additional Ambient Light Sensor
    Sensitivity and optional delay adjustment on case
    Highest quality wide view ADF available
    Constant UV/IR protection
    Adapts to standard magnifying lens

    1.1.1 DIN Rating
    Suitable for all types of electro-arc welding, including covered electrodes, MIG/MAG, TIG/WIG, plasma welding and cutting.
    NOT FOR LASER OR GAS WELDING.

    Characteristics

    Certified to EN 12941 1998 + A2:2008 (TH2)
    Certified to EN 166 2001 1 B
    Certified to EN 175 1997
    Certified to EN 379 2003 + A1: 2009 3/9-13

    The PX5 changes the way people experience clean filtered air across multiple industries – from medical and chemical settings, through to the profoundly harsh environments of foundries.

    The PX5 is the result of years of product refinement, designed with new functional capabilities that increase your ability to perform, while enhancing your experience of comfort. The PX5 redefines what it means to be a powered air purifying respirator.

    Weighing just 1.16 Kg with the HEPA cartridge/filter fitted, and between 1.65 Kg and 1.7 Kg with a gas cartridge/filter fitted, the PX5 allows you to get more out of your day by reducing the effects of fatigue. Through strategically distributing its weight with its vertical mounting position and support from our flexi-belt system, the PX5 contours to your body for maximized comfort and stability.

    With sleek considered surfaces, quick release mount lock system and certification for IP65 in use and IP67 with cleaning kit in place, the PX5 enables you to efficiently disinfect the unit, reducing downtime and ensuring the system is ready to protect you again.

    The PX5 is offering 3 air flow speed: 180, 210, and 230 lpm.

    The PX5 is truly the hallmark of powered air purifying respirator capabilities and their practical application.

    Features & Benefits

    • High-Efficiency Filtration: Removes up to 99.97% of particulates down to 0.12 microns (HEPA), with options for combined gas/vapor filters (OV/AG/HE, Multi-Gas, A2P, ABEK1P).
    • Ingress Protection: Certified to IP65 in use, and IP67 when the cleaning kit is in place, allowing for submersion during decontamination.
    • User Interface & Safety: LED interface indicates airflow (170-230+ lpm), fan speed (3 speeds), and battery level. It includes audible, visual, and vibrating alarms.
    • Compact & Ergonomic: Weighs 1.16kg (2.55lbs) with a HEPA filter and 1.65-1.7kg with gas cartridges. Designed to contour to the back for optimal weight distribution.
    • Battery Life: Long-life lithium-ion battery lasts 8–12+ hours depending on speed and filter type.
    • Filter Safety System: The filter door cannot be mounted without a filter present.

    Technical Specification

    Document Download

    Documentation File Format Size

    Z4 Welding Instructions PDF 4.4 MB
    Download
    PX5 PAPR Instructions PDF 3.3 MB
    Download

    What's In The Box

    Z4 Respirator Welding/Grinding Starter Pack, includes:

    • ADF lens
    • PX5® Powered Air Purifying Respirator (PAPR)
    • PX5® Breathing tube
    • 2'' Flame Retardant Belt Assembly
    • Rechargeable Battery and Charging Bank (EU and UK plug)
    • 1 x HEPA (P) filter
    • 1 x Spark Arrestor
    • 1 x pack of Pre-filters (10pk)
